Cleaning of Dust Box
1. Move the two side clips of the dust box, open the fencing plate and pour off dust (as shown on Figure 1);
2. Clean it with the cleaning brush (as shown on Figure 2).
Figure 1 Figure 2 Figure 3
Assembly & Disassembly of Brushes
• Force the locking bar forward and raise the cover by your right thumb, then raise the brushes.
• Insert the main brush and floor brush into the holes before closing the cover in assembly.
