Installation steps
1. The unit should be placed on a stable, smooth surface (use the packaging). Do not
apply force onto the controls protruding from the hob.
2. Fix the hob on the work surface by screw 4 brackets on the bottom case of hob (see
picture) after installation.
3. Adjust the brackets to the thickness of the work surface.
A B C D
Screw Bracket Screw hole Bottom case
Glass
Retaining bracket
Screw ST 3.5*8
Bottom
Worktop
