PRODUCT OVERVIEW
1 Main board 13 Burner pot
2 Vacuum 14 Ash box
3 Screw conveyor motor 15 Ash loading plate, front
4 Screw conveyor 16 Conversion fan
5 Hopper 17 Smoke outlet
6 Grid in the hopper 18 Fresh air pipe
7 Control panel 19 Power switch
8 Top cover 20 Fuel tank sensor
9 Cleaning rod for the ash 21 Explosion-proof cover
10 Guide re plate 22 Exhaust fan
11 Ignition rod 23 Ashtray cover
12 Door handle
