PRODUCT OVERVIEW
No. Part Name Qty No. Part Name Qty
1 Top plate 1 8-2 Gas connection 1
2 Ceramic burner head 1 9 Control knob 1
3 Bracket 1 10 Valve housing 1
4 Piezo electrode 1 11 Grill body 1
5 Thermocouple 1 12 Foot 4
6 Switch panel 1 13 Cooking grill bracket 3
7 Battery box 1 14 Holder 1
7-1 Wire for battery box 2 15 Cooking grill 1
8 Gas valve 16 16 Drop pan 1
8-1 Injector 17 17 Rack 1
