Wall mount
1. Take out 4 brackets, 6 expansion screws and 6 screws out from the box, and
x 2 brackets onto the wall ccording to the distances between holes of the
bracket, as depicted in the picture below.
2. Fix 2 brackets onto the bottom of product, as depicted in the picture below.
Unit: mm
General view
General view
Mounting hole 1000 W
Mounting hole 2000 W
