General Installation:
Adjusting Arm Length
9
10
11
Now it is time to adjust the length of the
arm.
Pull on the intermediate tube and end tube
with eyelet bolt to slide out arms.
Adjust the tubes so they are evenly spaced.
Leave at least a 1-2 inch gap
between the end of the eyelet
bolt and the front rail.
The eyelet bolt should be facing
up and down, meaning you
would not see the open circle
when looking from above (as
seen to the left)
1-2 INCH GAP
7
