ENGLISH
BATTERY REPLACEMENT
Unscrew the Power Button / Battery Cap
9
by turning counterclockwise. Remove and recycle
three exhausted AAA batteries. Install new batteries. Screw Power Button / Battery Cap into
place, seating fully to ensure a tight seal, using caution not to damage the O-ring.
CUSTOMER SERVICE
KLEIN TOOLS, INC.
450 Bond Street Lincolnshire, IL 60069 1-877-775-5346
customerservice@kleintools.com www.kleintools.com
CLEANING
Be sure level is turned off and wipe with a clean, dry lint-free cloth.
Do not use abrasive
cleaners or solvents.
STORAGE
Remove the batteries when level is not in use for a prolonged period of time. Do not expose to high
temperatures or humidity. After a period of storage in extreme conditions exceeding the limits mentioned in
the General Specifications section, allow the level to return to normal operating conditions before using.
WARRANTY
www.kleintools.com/warranty
DISPOSAL / RECYCLE
Do not place equipment and its accessories in the trash. Items must be properly disposed
of in accordance with local regulations. Please see www.epa.gov or
www.erecycle.org for additional information.
GENERAL SPECIFICATIONS
Klein Tools LBL100 is a Magnetic Laser Bubble Level that projects a laser line and spot. The
laser line and spot project parallel to the base of the level at a height of 1/2" (12.7 mm) above the
base (FIG. 1). Magnets in the base of the level allow it to attach to ferromagnetic surfaces, and a
V-groove along the top allows it to be centered along pipe and conduit. There is also a leveling base
included for use on unlevel surfaces.
• Interior Working Range: 75 ft. (22.86 m)
• Laser: Class IIIa, 630 to 670nm, Max. Power <5mW
• Batteries: 3x AAA 1.5V Alkaline
• Operating and Storage Altitude: Up to 6562 ft. (2000 m)
• Operating and Storage Temp: 32° to 122°F (0° to 50°C)
• Relative Humidity: <85% non-condensing
• Dimensions: 1.89" x 7.3" x 0.85" (48 x 185 x 22 mm)
• Weight: 11.5 oz. (326 g) including batteries
• Pollution Degree: 2
• Drop Protection:
3.3 ft. (1 m)
• Ingress Protection: IP54 Dust & water resistant
• Accuracy: Vials: 0.043°
Spot: ±0.02" (±0.5mm) at 39.4" (1m) from Level
Line Tilt relative to Base: ±0.02" (±0.5mm) at 19.7" (0.5m) from Spot
Specifications subject to change.
FEATURES AND FUNCTIONS (FIG. 1)
POWER ON/OFF
Press and release the Power Button
9
to turn the laser on or off.
LEVELING BASE
The LBL100 magnetically attaches to the Leveling Base for use on unlevel surfaces. Make sure that
the 1/4-20 Tripod Mount
10
is centered over the Centering Pin
11
, attach to base, and adjust the
Thumb Screws
12
until the Horizontal
4
and Cross
6
vials read level (air bubbles are centered).
WARNINGS
To ensure safe operation of the instrument, follow these instructions. Failure to observe these
warnings can result in serious personal injury. Retain these instructions for future reference.
• LASER RADIATION, Class IIIa laser. DO NOT direct
laser beam into eyes, DO NOT stare into the beam, or
DO NOT view directly with optical instruments as this
can cause severe and permanent eye damage.
• DO NOT use the LBL100 if it appears to be damaged.
• This product should not be used in any location that could result in somebody looking at or having
their eyes inadvertently irradiated by the laser beam, as this could result in severe eye injuries.
• This instrument should be powered off following use to minimize the risks of inadvertent exposure
to hazardous laser irradiation that could result in severe eye injuries.
• The instrument should be securely located in a tidy work environment prior to operation, as
unexpected drops or movement of the instrument may result in damage to the instrument, and
increases the risk of inadvertent exposure to laser radiation that could result in eye injuries.
• Always wear approved eye protection.
