General
Frequency Range VHF: 136~174MHz
UHF:430-470MHz: 400-440MHz: 470-512MHz
Channel Capacity 16 (15+S)
Channel Spacing 25.0kHz / 12.5kHz
Frequency Stability ±2.5PPM
Operating Temperature -25~+55°C
Antenna Impendence 50Ω
Operating Voltage 7.4V
Dimension (W×H×D) 2.165” × 4.37” × 1.26”
Weight (with antenna & battery) 232g
Battery 1300mAh(Li-ion Battery)
Transmitter:
RF Power (H/L) UHF: 4W/1W VHF: 5W/1W
Modulation Type 16kΦF3E/ 8kΦF3E
Modulation Limiting ±5kHz / ±2.5kHz
FM Distortion ≤5%
Residential FM -45dB / -40dB
Adjacent Channel Power -70dB / -60dB
Spurious & Harmonics ≤-36dBm
Receiver:
Sensitivity 0.22uV/ 0.25uV
Adjacent Channel Selectivity 70dB/60dB
Intermediation Reject Ratio 65dB
Spurious Response Reject Ratio 70dB
S/N 45dB/ 40dB
Audio Power Output 600mW
Audio Distortion ≤5%
Specication
14 www.blackboxradios.com
