22
5.2 Water Tank and Cloth
1.Disassemble Water Tank
Remove out
water tank
Remove out
cloth part
Remove cloth
5.Routine Maintenance
5.1 Main Brush
1.Turn the robot over unlatch and remove the
main brush cover.
2.Take out the main brush, remove and clean
its bearings.
3.Use the supplied cleaning brush tool to
remove any dust or entangled hair.
4.Re-install the cap and bearings following
the lock direction
5.Re-insert the main brush and replace the
brush cover.
Press latch
main brush cover
main brush
cleaning brush
To Next Page
