SPEAKER PLACEMENT GUIDELINES
+3 dB SPL and
ADDED BASS
+3 dB SPL and
ADDED BASS
+3 dB SPL and
ADDED BASS
<=30 FT
(9M)
To maintain consistent volume levels across an area, space speakers on wall based on their
90 coverage patterns aimed down to listening area.
To reduce phasing issues affecting sound quality, in areas up to 30 feet (9.1M) wide where
speakers are mounted on opposite walls, stagger speakers so none directly face ones on
the opposite wall.
Wall Positioning
Speaker Spacing
