WALL MOUNT TEMPLATE
MAKE SURE TEMPLATE IS LEVEL BEFORE DRILLING PILOT HOLES!
SPEAKER WILL REST 3/8" (9.5mm) DOWN FROM WHERE HOLES ARE DRILLED
Total speaker width 40" (1015.8mm)
Total speaker height 4.25” (107.6mm)
Leave at least 1" (25.4mm) of space above speakerLeave at least 1" (25.4mm) of space above speaker
Pilot
Hole
Pilot
Hole
