Klipsch Reference Premiere RP-450C User Manual

Service Manual – Consumer
17
Once the screws have been removed, the tweeter will look as such.
Next, replace the tweeter back into position on the horn lens, and reattach the screws.
Plug the wires on to the new tweeter, and slide the silicone covers back over the terminals.
Place the tweeter back into position inside the cabinet and replace the six (6) screws.
Replace the horn lens by setting into position and gently pressing the trim ring around the
edge, verifying the clips on the back are locking into place. Once this is done, the trim ring
should sit flush with the front of the speaker

Klipsch Reference Premiere RP-450C Specifications

General

Brand	Klipsch
Model	Reference Premiere RP-450C
Category	Speakers
Language	English
