Name: Klipsch Reference Premiere RP-504C
Brand: Klipsch
Rating: 5 (1 reviews)

To Next Page

To Previous Page

FIGURE 2

CENTER CHANNEL

FIGURE 4

WALL MOUNTING

FIGURE 3

STANDARD CONNECTIONS

SUB SUB

X=Y=Z

L R

Front Right Front Left

SUB SUB

X=Y=Z

L R

Front Right Front Left

SUB SUB

X=Y=Z

L R

Front Right Front Left

SUB SUB

X=Y=Z

L R

Front Right Front Left

6’ - 15’

Optional Side Surround Placement (Option A is preferred)

#10

2.5" - 3" panhead wood screws

Mount in wall stud or use

anchors - leave 1/4" exposed

VIA KEYHOLE

VIA THREADED INSERT

CAUTION!

Do not use keyhole

for ceiling mounting!

BELOW

ABOVE

FIGURE 1

SPEAKER PLACEMENT IN LISTENING AREA

3/8-16 x 0.5”

*Wall brackets not included
