Klipsch Reference Premiere RP-8060FA User Manual

FIGURE 2
CENTER CHANNEL
FIGURE 4
WALL MOUNTING
FIGURE 3
STANDARD CONNECTIONS
SUB SUB
TV
C
X
Y
Z
sL
sR
sL
sR
X=Y=Z
L R
Front Right Front Left
SUB SUB
TV
C
X
Y
Z
sL
sR
sL
sR
X=Y=Z
L R
Front Right Front Left
SUB SUB
TV
C
X
Y
Z
sL
sR
sL
sR
X=Y=Z
L R
Front Right Front Left
SUB SUB
TV
C
X
Y
Z
sL
sR
sL
sR
X=Y=Z
L R
Front Right Front Left
6’ - 15’
Optional Side Surround Placement (Option A is preferred)
#10
2.5" - 3" panhead wood screws
Mount in wall stud or use
anchors - leave 1/4" exposed
VIA KEYHOLE
VIA THREADED INSERT
CAUTION!
Do not use keyhole
for ceiling mounting!
BELOW
ABOVE
OR
OR
FIGURE 1
SPEAKER PLACEMENT IN LISTENING AREA
3/8-16 x 0.5”
*Wall brackets not included

Klipsch Reference Premiere RP-8060FA Specifications

General

Bass reflex	Yes
Certification	CE
Product color	Black, Walnut
Housing material	MDF
Recommended usage	Universal
Impedance	8 Ω
Frequency range	32 - 25000 Hz
RMS rated power	150 W
Crossover frequency	1750 Hz
Peak Music Power Output (PMPO)	600 W
Speaker type	-
Speaker placement	Floor
Audio output channels	- channels
Number of woofer drivers	1
Driver diaphragm material	Titanium
Woofer diameter (imperial)	8 \
Tweeter diameter (imperial)	1 \
Connectivity technology	Wired

Weight and Dimensions

Depth	503 mm
Width	277 mm
Height	1095 mm
Weight	32200 g
