Klutch 5793513 - Parts List

Page 23 of 28
Parts List
Reference
Part Number
Part Description
Quantity
1
1
Base
1
2
2
Column Support
1
3
3
Flat Washer 10
4
4
4
Spring Washer 10
4
5
5
Bolt M10×35
4
6
6
Socket Head Cap Screw M10×10
4
7
7
Column
1
8
8
Rack
1
9
9
Spindle Feed Handle Bar
3
10
10
Spindle Feed Hub
1
11
11
Spring Pin 5×30
1
12
12
Spindle Feed Shaft
1
13
13
Lock Knob
3
14
14
Depth Stop Collar
1
15
15
Scale Label
1
16
16
Set Screw M6×10
2
17
17
Collar
1
18
18
Rivet
1
19
19
Toothed Washer 4
2
20
20
Flat Washer
2
21
21
Spring Washer 4
2
22
22
Screw M4×8
8
23
23
Pointer
1
24
24
Cover Plate
1
25
25
Flat Washer 4
7
26
26
Junction Box
1
27
27
Flat Washer 5
4
28
28
Cross-Shape Screw M5×8
4
29
29
Switch Panel
1
30
30
Drill Press Power Switch
1
31
31
Tapping Screw St3.5×10
3
32
32
Work Table
1
33
33
Rivet 2×3
5
34
34
Scale Label
1
35
35
“0”-Degree Label
1
36
36
Table Lock Handle
1
37
37
Handle Grip
1
38
38
Gear
1
39
39
Axis Pin
1
40
40
Set Screw M5×10
1
41
41
Table Crank
1
42
42
Nut M10
2
43
43
Table Crank Handle
1
44
44
Socket Head Cap Screw M8×90
1
45
45
Worm Gear
1
46
46
Table Support
1
47
47
Table Support Arm
1
48
48
Table Clamp
1
49
49
Table Clamp Handle
1
50
50
Spring Washer 16
1
51
51
Bolt M16×35
1
52
52
Sealing Gasket (B)
1
53
53
Oil Bottle Cap
2
54
54
Sealing Gasket (A)
1
55
55
Hollow Connecting Bolt
1
56
56
Oil Bottle
2
57
57
Chuck
1
58
58
Arbor
1
59
59
Spindle
1
60
60
Ball Bearing 6006
1
61
61
Spindle Sleeve
1
62
62
Rubber Ring
1
63
63
Ball Bearing 6004
1
64
64
Retainer Ring 19
1
65
65
Retainer Ring 47
2
66
66
Ball Bearing 6205
2
67
67
Bearing Spacer Ring
1
68
68
Spindle Housing
1
69
69
Spindle Pulley
1
70
70
V-Belt A-785
1
