CTE-5202 Electronic Room Thermostat with LCD Display 4 Installation and Operation Guide
Accessories
Maintenance
Removedustasnecessaryfromholesintopand
boom.Cleanthedisplaywithso,dampclothand
mildsoap.Eachcomponentisdesignedfordepend-
able,long-termreliability,andperformance.Careful
installationwillalsoensurelong-termreliabilityand
performance.
© 2013 KMC Controls, Inc. 821-019-02B
KMC Controls, Inc.
19476IndustrialDrive
NewParis,IN46553
574.831.5250
www.kmccontrols.com
info@kmccontrols.com
NOTE: For specications and other information,
see the CTE-5202 Data Sheet.
Additional Resources
Thelatestsupportlesarealwaysavailableonthe
KMCControlswebsite(www.kmccontrols.com).
Important Notices
Thematerialinthisdocumentisforinformation
purposesonly.The contents and the product it
describes are subject to change without notice.
KMCControls,Inc.makesnorepresentationsor
warrantieswithrespecttothisdocument.Innoevent
shallKMCControls,Inc.beliableforanydamages,
directorincidental,arisingoutoforrelatedtothe
useofthisdocument.
NOTE: For detailed applications, cross-references,
troubleshooting, accessories, and
other information, see the CTE-5202
Applications Guide.
HMO-1161
 Wallplate,allowsmounting
tohorizontal2x4",4x4",and
otherboxes,lightalmond
HMO-1161W HMO-1161inwhite
HPO-0044 Replacementcoverhexscrews
HPO-1161 Foaminsulatinggasket
REE-50xx Electricrelaymodulesforstag-
ing,fancontrol,andreheat
STE-140x Ducttemperature(TypeIII)sen-
sors
STE-1454/1455
 Strap-ontemperature(TypeIII)
sensors
External Input (AI1)
Hot/Cold Air Changeover
Forhot/coldairchangeoveronSequence1or2,
connectachangeover(temperature)sensortothe
AI1input.ThesensorshouldbeaTypeIIIthermistor
(10Kohm@77°F),suchasaKMCSTE-140xduct
sensororSTE-1454/1455 strap-onsensor.(Aninter-
nal10KohmpullupresistorisprovidedonAI1.)
Leavesensoroforcontinuouscoldairmode.
Unoccupied/Standby Setback
ContactclosureacrossAI1andCommoninitiatesthe
standbysetbackosetsequence,whichcausesthe
coolingsetpointtoincreaseandtheheatingsetpoint
(inSequence2or3)todecreasebytheamountofthe
setbackoset.(Thissetbackdoesnotapplyduring
themorningwarm-upofSequences1and2.)
