CTE-5202 Electronic Room Thermostat with LCD Display 3 Installation and Operation Guide
NOTE: AO1istypicallyusedtocontrolthecool-
ingoutput(primaryairdamperorcooling
valve),andAO2isusedtocontroltheheat-
ingoutput(VAVreheatorheatingvalve).
2° F
2° F
2° F
AO2 Disabled
(12 Volts)
SEQUENCE # 1: SINGLE DUCT COOLING, FAN BOX (with REE-5002, REE-5017, or REE-5024)
COLD AIR SEQUENCE
12 Volts
AO2 (DA)
0-12 Volts
AO1 (DA)
Setpoint
AO1 MIN
HOT AIR SEQUENCE (Morning Warm Up)
AO1 (RA)
AO1 MAX
AO1 MAX
AO1 MIN
Temp. Increasing
6 Volts
Setpoint
2° F
Of Loop
10%
2° F
2° F
AO1 MIN
AO1 MAX
AO1 MAX
AO1 (RA)
HOT AIR SEQUENCE (Morning Warm Up)
AUX
AO1 MIN
COLD AIR SEQUENCE
AO1 (DA)
AO2 (RA)
0 Volts
12 Volts
SEQUENCE # 2:
SINGLE DUCT COOLING WITH REHEAT AND AUXILIARY FLOW
AO2 Disabled
(0 Volts)
Temp. Increasing
Cooling
Setpoint
Heating
Setpoint
Heating
Setpoint
SEQUENCE # 3:
INDEPENDENT HEATING AND COOLING CONTROL
(Dual Duct VAV, Baseboard, Single Zone AHU)
AO2 MAX
AO2 MIN
AO2 (RA)
AO1 (DA)
AO1 MIN
AO1 MAX
Cooling
Setpoint
Heating
Setpoint
Temp.
Increasing
2° F 2° F
NOTE: For additional details of sequence op-
erations, see the CTE-5202 Applications
Guide.
TheADVANCEmenuenableschanging(viathe
Up/Downbuons)thevaluesof:
• DEAD BD—Deadbandor“minimumsetpoint
dierential”(adjustable from 1 to 10° F, 2° F default)
• SETBACK
—Standby/unoccupiedsetbackoset
(adjustable from 0 to 10° F, 2° F default)—doesnot
applytomorningwarmup
• PROP BD—Loopproportionalband(adjustable
from 1 to 10° F, 2° F default)
• Rm OFST
—Roomtemperatureoset(adjustable
±5° F, 0 default)
• CNG OVR
—changeovertemperature(adjustable
from 55 to 85° F, 77° F default)
• I TIME—
Loopintegraltime(adjustable from 0 to
60, 30 minutes default, 0 = cancel integral action)
TheSYSTEMmenuenableschanging:
• Sequence(SEQ1,SEQ2,orSEQ3)—see
Sequencescharts
• °F(ENGLISH)or°C(METRIC)
• BLANK—Display
blanking(NOorYES)—
whenblanked,thetemperaturewilldisplayfor
nomorethan30secondsaerabuonispushed
Whendone,navigateto(ashing)Exittosave
changes.Leing the menu time-out (about 30
seconds) will not permanently save changes.
