Signal measure at 1300 RPM - Direct connection on car Battery via adaptor
0.5V/DIV
Time 0.5ms/DIV
Connection direct on battery: Less noise,
Signal is very good and RPM8000PRO works!!
Value 500mV/DIV-0.5ms/DIV - about 2000Hz
(Signal must be >200mV)
