ENGLISH
NOTICE
ATTENTION: PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS
AND WARNINGS BEFORE ASSEMBLING, INSTALLING OR USING THIS
PRODUCT.
Tools Required
• 9/16” SOCKET
• 9/16” WRENCH
• 5/16” SOCKET
• 7/16” SOCKET
• 7/16” WRENCH
• SCREWDRIVER, STRAIGHT BLADE
• SCREWDRIVER, PHILLIPS HEAD
Parts List
• MODEL 500 POWER CREW * QTY. 1
• MODEL 497 LIFT BRACKETS* QTY. 1
• BRACKETS, SCREEN MTG. QTY. 2
Bolt Kit #32-1180
• BOLT, M4 X18MM PHILLIPS HEAD QTY. 4
• BOLT, M4 X30MM PHILLIPS HEAD QTY. 4
• Bolt, M6 x 12MM PHILLIPS HEAD QTY. 4
• BOLT, M6 x 30MM PHILLIPS HEAD QTY. 4
• BOLT, M8 x 35MM PHILLIPS HEAD QTY. 4
• WASHER, LOCK ¼” QTY. 4
• WASHER, FLAT 1/4 QTY. 4
• WASHER, LOCK 5/16” QTY. 4
• BOLT, 1/4-20 x 5/8 HEX HD QTY. 6
• NUT, WHIZ 1/4-20 QTY. 6
• SHIM, HORSESHOE 1/16” THICK QTY. 12
• SHIM, HORSESHOE ¼” THICK QTY. 4
* NOTE: FOR INSTALLING BOTH THE MODEL 500 POWER CREW, AND THE 497
LIFT BRACKETS, REFER TO THE INSTRUCTION SHEETS INSIDE EACH KIT.
TV Specications (not included in 118-02 but must meet these specs)
• 40” TV
• MINIMUM OF 2 HDMI PORTS
