Setup Instructions:
Step 1: Install Front Axle
Please take your time to carefully complete all steps before operating your
new KneeRover
®
scooter. First, place the front axle with caster wheels
under the scooter frame, ensuring the round bolts by the wheels are facing
up (as shown in left and right photos). Align the axle and frame holes,
insert the clamp and washer into each hole, and tighten the clamps in a
clockwise motion until the axle is tight against the frame. Press the clamp
lever down firmly until it touches the frame, to lock it in place. The right
photo shows how the clamp should look when properly installed.
Step 2: Install Steering Mechanism
Attached to the front axle you will see two gray bars (the tie rods). Take
one of the tie rods and position it under the black plate that is attached to
the frame. Next take the other tie rod and place it on top of the black plate.
Place the washer on top of the upper tie rod and then thread the bolt from
the bottom to the top, through the tie rods. Finally thread the cotter pin
through the hole on top to lock the assembly in place.
Step 3: Install Steering Column
The steering column will be in a folded position when unpacking. When
facing the front of the KneeRover
®
scooter, raise the steering column
and push the security pin in the clamp to the left (as shown in left photo)
to allow the column to lock into place. Raise the clamp lever upward
and tighten by turning it clockwise. Finally, push clamp lever down
firmly to secure the steering column (as shown in center photo).
Reverse these steps when needing to lower steering column for
transport. Once knee platform is installed, use the black knob (shown in
right photo) to set the handlebars at a comfortable height for operation.
Step 4: Install Knee Platform & Attach Basket
The knee platform is designed to be used with either the right or left leg.
Remove the knee platform from the bottom of the KneeRover
®
scooter
by removing the locking pin and loosening the clamp. Next insert the
knee platform post into the receptacle tube and set the knee platform at
your desired height for use by inserting the locking pin through the
aligned holes. Finally, tighten the clamp to secure the knee platform in
place. Removable basket attaches to the steering column.
