504G3 SERIES TRACTOR OPERATION MANUAL
97
2.2. ASSEMBLY
See drawing no. 504G3.53.001.
Use only bolts M16 8.8.
Tightening torque: 225 Nm.
CAUTION
Secure all pins with cotter.
