L
ASSEMBLY INSTRUCTIONS
Hardware Used
4
AA
x 4ST4.8 x 10 mm
Screw
3.
Push and tighten the preassembled
screws on the assembled unit from Step
1 to the key slots of base (E). Tighten the
ST4.8 x 10 mm screws (AA) to the front
edge of the base (E) to connect left side
(B) and right side (C) to base (E).
4. Flick the plastic clips on the inside
slide (N) to detach the outside slide
(M) from the inside slide (N). For the
plastic clip on the left side, please
press down and slide outside slide
(M) off inside slide (N). For the
plastic clip on the right side, please
push up and slide outside slide (M)
off inside slide (N).
Left sideRight side
M
N
6
Lowes.com
AA
3
C
A
E
E
E
B
B
C
A
C
A
E
