19
CARE AND MAINTENANCE
15. Removing the Blade
WARNING
Always protect your hands by wearing heavy
gloves or wrapping the cutting edges with
rags or other materials when performing any
maintenance on the mower blade. Always
remove the battery pack when servicing or
transporting the mower.
NOTICE: The following tools are required for
replacing the blade:
9/16" (14mm) wrench
Torque wrench
Manual screwdriver or metal rod with a diameter
of 5/16" (8mm)
Manual screwdriver or metal rod with a diameter
1/4" (6.35mm) or less
a. Stop the motor; remove the battery pack from
the mower.
b. Turn the mower on its side.
c. While wearing protective gloves, place a metal
rod (e.g., a 3.5" length screw bit) with diameter
less than 5/16" (8mm) into the xing hole to act
as a stabilizer.
d. Use a 9/16-inch (14mm) wrench to turn the
blade bolt counterclockwise to loosen it.
e. While wearing protective gloves, remove the
bolt, outer ange, and the blade (Fig. 15b).
15a
Stabilizer
Loosen
15b
Fan
Inner ange
Blade
Outer ange
Bolt
