5
OPERATING INSTRUCTIONS
A
B
A
D
6. The level is equipped with a strong mag-
netic base for use with ferrous surfaces,
eliminating the need for the straps.
6
4. While working on any uneven surface, use the adjustable foot to level the laser in a hori-
zontal position.
• Attach the adjustable foot (C) and the magnetic line lens (B) to the level (A).
• Press the ON/OFF switch to activate the laser function.
• Using the horizontal bubble to indicate levelness, turn the knob on the adjustable foot to
raise or lower the laser while working on uneven surfaces.
4
5. While working on non-ferrous objects,
fasten the level (A) using the hook and loop
straps (D).
USE WITH HOOK AND
LOOP STRAPS
USE WITH
MAGNETIC BASE
5
USE WITH ADJUSTABLE FEET
