12
OPERATING INSTRUCTIONS
5. Hanging/Mounting the Fan
Your fan has a variety of hanging options. Choose
the option that is best suited for your location.
NOTE: The portable fan can be hung in a vertical
or horizontal position. Be careful not to hang the fan
in such a way that it prevents normal fan operation
or damages the cord.
Hanging the fan using the key hole:
a. Place the wide portion of at least two of the key
holes (I) over the heads of a screws.
b. Slide the portable fan down until the screws are
inside the narrow portion of the key hole and
the fan is secure.
Hanging the fan using the hooks:
a. Pull the hooks (F) completely out of their slots
and rotate them as needed.
NOTE: Hooks will not rotate until they are fully
extended.
b. Hang the fan from a sturdy location.
6
5
I
