ASSEMBLY INSTRUCTIONS
5. To install battery
• Lift and hold up the battery door (M).
• Align raised ribs on battery with grooves in the
mower’s battery port.
• Make sure the battery release button snaps in
place and that battery is fully seated and secure in
the mower before beginning operation.
• If the machine is not going to be used immediately,
remove the battery.
• Close the door.
5
M
6. To remove battery
• Release the bail switch (P) to stop the mower.
• Press the battery release button (O) on the mower.
This will cause the battery to raise out of the tool
slightly.
• Hold battery door open before pressing battery
release button.
• Remove battery from the mower.
6
O
P
WARNING: Always remove battery from your tool
when you are assembling parts, making adjustments,
cleaning, or when not in use. Removing battery will
prevent accidental starting that could cause serious
personal injury.
