Kobalt KPC 2040-06 User Manual

7
ASSEMBLY INSTRUCTIONS
4. INSTALL THE BATTERY PACK
• Pull back on the hinge lock lever (I).
• Unhook the hinge (I) from the battery door (J).
• Open the battery door (J).
• Align the lift ribs on the battery pack (K) with the
grooves in the battery compartment.
• Push the battery pack (K) into the battery compartment
until the battery pack (K) locks into place.
• When you hear a click, the battery pack is installed.
• Close the battery door (J) and lock the hinge (I).
5. REMOVE THE BATTERY PACK
• Pull back on the hinge lock lever (I).
• Unhook the hinge (I) from the battery door (J).
• Open the battery door (J).
• Push and hold the battery release button (L).
• Remove the battery pack (K) from the machine.
J
I
K
4
I
J
I
K
5
L
