ASSEMBLY INSTRUCTIONS
kobalttools.com
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
4. Install hose holder (A) onto back side of upper
handle (B). Secure with two screws (CC).
1
4
2
A
CC
B
Hardware Used
Screw
x 2
CC
AA BB CC DD
Screw
Qty. 2
Axle Pin
Qty. 2
Screw
Qty. 2
Cotter Pin
Qty. 2
3
3
2
2
1
G
B
3. Press buttons on lower frame (G) extensions
and install handle (B). Lower frame extensions
will click when handle is in proper position.

Kobalt KPW 2N1 Specifications
