9
ASSEMBLY INSTRUCTIONS
kobalttools.com
7. Pull back on collar at one end of soft PVC hose (N).
Push rmly to connect hose to spray gun (K). Twist
collar to secure. Conrm hose is locked into spray
gun by slightly pulling on them. The hose is now
securely attached to spray gun.
3
2
7
1
K
N
N
6
F
G
6. Place power washer unit (F) into position on the
lower frame (G).
5. Slide spray gun holster (M) into place on the
upper handle (B).
5
B
M
