10
ASSEMBLY INSTRUCTIONS
g. To install the lter, slide it over the oat cage. Align the lter tabs with the motor housing
notches and turn it 1/2 inch clockwise to lock it in place.
h. Replace the motor housing and secure both tank latches.
NOTICE: Keep lters clean. Efciency of the vacuum is largely dependent on the lters. Dirty
lters will reduce the air ow and the efciency of the ltration system. Do NOT machine wash
or dry. Clean the lter with a gentle ow of water. Not squeeze or wring the lter, which will
damage the lter.
3. Pickup/Blower
The vacuum can be used for debris pickup or as a
blower, depending on the port used.
To attach hose for debris pickup
a. Insert the large end of hose (I) into the intake
port (G) of the motor housing, lining up the tabs
on the hose with the notches in the port.
b. Twist the base of the hose to secure it and form
a tight t.
To attach as blower
a. Insert the large end of hose into the blower port
of the motor housing
(H), lining up the
tabs on the hose with the notches in the port.
b. Twist the base of the hose to secure it and form
a tight t.
c. Attach one of the accessories to the other end
of the hose. Twist to form a tight t.
Use 1-1/4 inch opening accessories.
3a
I
3b
