SAFETY INFORMATION
HARDWARE CONTENTS
• Carefully read the caution and warning messages.
4
Part
Description
Quantity
Picture Picture
Part
Description
Quantity
M10 Nut
2
2
AA
M10 Flat
Washer
BB
2
Shoulder Bolt
CC
5
M8 × 40mm Bolt
DD
6
M8 × 45mm Bolt
EE
3
M8 × 60mm Bolt
FF
1
Motor Shaft Pin
GG
18
M8 Nut
HH
End Cap
(Pre-installed)
2
3
II
Cotter Pin
JJ
2
M8 U-Bolt
Retaining Clip
(Pre-installed)
(Pre-installed)
(Pre-installed)
(Pre-installed)
(Pre-installed)
M8 Nut
M8 Flat
Washer
M8 Spring
Washer
KK
LL
NN
MM
OO
PP
Follow owner’s manual to ensure proper assembly of mixer, using the parts list in conjunction with
procedures.
• Retain these Instructions for future reference.
• Parts may have sharp edges. Wear gloves when assembling the mixer.
• Store appliance indoors when not in use.
• Keep out of reach of children.
• Review these instructions before operating mixer.
• All bolts should be fastened with the nuts facing toward the center of the mixer.
• Do not tighten fasteners until final alignment is achieved.
• Safety glasses and gloves should be worn while operating this mixer.
• All wiring, electrical connections, and system grounding must comply with the National
Electrical Code (NEC) and with any local codes and ordinances. Contact a local licensed
electrician for further information.
• Do not expose to rain, store indoors.
• A ground fault interrupter (GFI) protected circuit is recommended for all outdoor electrical
• Keep motor operating area as dry as possible.
• Always disconnect the power before servicing.
devices.
1
4
Retaining Clip
Handle
1
4
4
CAUTION - ALWAYS START MIXER EMPTY
WARNING - ELECTRICAL PRECAUTIONS
WARNING - RISK OF ELECTRICAL SHOCK
