Kobalt VT636201 User Manual

27
EXPLODED DRAWINGS
For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258),
8:00 am - 8:00 pm, EST, Monday - Friday.
PART DESCRIPTION PART NUMBER QTY.
1
COMPRESSOR PUMP VT490000SJ 1
2
MOTOR, 3.7HP 240V MC019700SJ 1
3
HEX HEAD BOLT, 5/16"-18 X 3/4" ST016000AV 4
4
WASHER, 5/16"
ST011200AV, ▲
4
5
SPINLOCK NUT, 5/16"-18 ST146001AV 4
6
SELF TAPPING SCREW, 5/16"-12 ST016500AV 4
7
BELT GUARD BACK
BG313200AV, ▲
1
8
BELT GUARD FRONT
BG313300AV, ▲
1
9
PLASTIC RETAINING CLIP
ST199700AV, ▲
4
10
MOTOR PULLEY PU017300AV 1
11
MOTOR KEY KE000900AV 1
12
SET SCREW, 1/4"-20 X 1/2" ST012200AV 1
13
HEX PIPE NIPPLE, 1/4" NPT HF002401AV 1
14
CHECK VALVE CV221519SJ 1
15
QUICK CONNECT FITTING, 1/4" TUBE X 1/8" NPT - 1
16
PLUG, 1/4" NPT ST022500AV 1
17
COMPRESSION NUT, 1/2" ST033001AV 2
18
ASME SAFETY VALVE, 175PSI V-215109AV 1
19
PRESSURE GAUGE, 300PSI GA031900AV 1
20
COMPRESSION FITTING ST159001AV 1
21
BRASS FERRULE, 1/2" TUBE ST032900AV 1
22
EXHAUST TUBE , 1/2" VT043300AP 1
23
SELF TAPPING SCREW, #10-3/8" ST073278AV 1
24
RUBBER FERRULE, 1/2" TUBE ST085200AV 1
25
PRESSURE SWITCH CORD GRIP CW209700AV 1
26
STRAIN RELIEF SCREW ST209800AV 1
27
HEX HEAD SELF TAPPIN SCREW. #8 X 3/8" ST074407AV 2
28
BELT, AX48 BT020401AV 1
29
PTFE TUBE, 1/4" X 13" ST117802AV 1
30
BELT GUARD BRACKET BG220400AV 1
31
DRAINCOCK, 1/4" D-1403 1
32
PRESSURE SWITCH CW218800AV 1
33
SELF TAPPING SCREW, #5-5/8"
ST073277AV, ▲
5
34
MOTOR POWER CORD EC012800AV 1
35
PUMP FLYWHEEL PU015901SJ 1
36
TANK, 60 GALLONS AR040000CG 1
REPLACEMENT PARTS KITS
▲
BELT GUARD KIT VT551953AV
kobalttools.com
