Specification
09
AK series professional audio power amplifier
Frequency Response(at 1 Watt)
Total Harmonic Distortion(THD)
Intermodulation Distortion60Hz
and 7KHz at 4:1from full rated
output to -30dB
Slew Rate
Voltage Gain
Damping Factor(8ohms)10Hz-
400Hz
Signal-to-Noise Ratio (below
rated power,20Hz to 20kHz.
A-weighted)
Crosstalk(below rated power)
At 1kHz
At 20kHz
Input Sensitivity for full
rated power at 8Ω
Input impedance(nominal)
Balanced
Unbalanced
1kHz(HIA)with0.5%THD
4Ω stereo(per channel)
8Ω bridge mono
Rated power /model
Performance
Construction
Ventilation
Protection
Cooling
Power cord specification
Chassis size( unit mm)
Net weight
8Ω stereo(per channel)
20Hz-20KHz,+0-1dB
<0.5%,20Hz-20KHz
=/<0.35%
>20V/us
>200
>100dB
-75dB
-58dB
0.775V or 1.4V
20K ohms
10k ohms
AK2-700
AK2-1300
AK2-1500
32.8dB 35dB 36dB 37.8dB 38.3dB
AK2-500
1900W 2250W
AK2-1000
3350W
4350W 4600W
7.5kg
482x227x88
2x950W 2x1650W2x1100W 2x2100W 2x2300W
2x500W
2x1000W2x700W 2x1380W 2x1520W
Protection against shor t circuits, no-load, on/off muting, RF interference.
Flow-through ventilation from front to back
Internal heat sinks with forced air. Fan cooled, speed regulated,
thermal protection
Plug Wire:：10A，250V 3x1.0mm
Power switch: It can turn on/off the amplifier. When turn on, the POWER
LED lights.
SIG
POWER
Fault LED: When circuit protection works, the LED will light, especially
when the heat-sink overheat or detect the DC voltage in the amplifier,
the LED will light. Turn on the amplifier within three seconds, the
amplifier is ready to work, the LED will shine. When finish start or the
problem is removed, the LED will extinguish, and resume working
normally.
FLT
CLIP
Clip LED: When the output signal distortion of the corresponding
channel exceeds 1%, the LED will light, because of the signal level
is too high, and have been cut-off.
Signal LED: when there is the input signal, the LED will light, if not,
please check the gain settings, if necessary, can increase the gain.
Check the input connection and signal audio source. If the Clip LED
shines a little or shows no signal, check the output wire whether it is
short-circuit or not.
Main Operation Key& Functions
Front Panel
04
AK series professional audio power amplifier
Gain control: use to set the output level of each channel
