Koch Jupiter - CONNECTION DIAGRAM

Input
FS2
Footpedal
Outputs
L (mono) R
EFFECTS UNIT
CONNECTION DIAGRAM
To Mixing Console
Line Input
JUPITER
COMBO
(internal
speaker)
4, 8 OR 16 OHMS
SPEAKER CABINET
(4 OHMS, SINGLE
CABINET ONLY)
8 OR16 OHMS
EXTENSION
SPEAKER CABINET
OR
To Mixing Console
Microphone Input
DI
BOX
Fuse: 100/120V - T3.2A
220/240V - T1.6A
VAC
80 Watts, 50/60Hz
115 230
100
~
Speaker Outputs Recording
Footswitch Channels
Effects Loop
Speaker
Emulated
output
Minimum Load 4 Ohm
1x16 Ohm - 35 Watt
2x16 / 1x8 Ohm - 45 Watt
2x8 / 1x4 Ohm - 50 Watt
Reverb
on/off
CoolHot
Ch2 Gain
Boost
Function of Right-Hand
Button on Footswitch
Output Power
To
FX-in
From
FX-out
