Koch Jupiter - BLOCK DIAGRAM; TECHNICAL SPECIFICATIONS

Bass Mid Treble Contour
Rever b
Gain
Gain
Volume
Volume
Coo l
Gai n B oos t
Hot
Inp ut
To FX Fro m F X
Fil ter
Rec ordin g
min . 4 Ohm s
Effects Loop
Speakers
+
Reverb
BLOCK DIAGRAM
TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE Input
From FX
To FX
100-230VAC, 50-60Hz
Effects Loop
Preamp
Power amp
Power amp
1M ohms
100K ohms
1K ohms
50 Watts
50W(rms) in 4 ohms
45W(rms) in 8 ohms
35W(rms) in 16 ohms
-10 dBV
1x 12AX7
1x 12AX7
OUTPUT IMPEDANCES
MAINS
OUTPUT POWER
SIGNAL LEVELS
TUBES
