KOCOM KCC SERIES - Table of Contents

21
Table of Contents
Model configuration 2
Precautions 3
Name of each part and Functions
- Front 4-5
- Back 6-11
Connection
1. Lens
1) How to use a Fixed Iris lens 12
2) How to use a DC Iris lens 12-13
3) How to use a Video Iris lens 13
4) How to connect an Auto Iris lens 13-14
2. How to adjust C/CS Mount 15
3. How to connect Power 16
4. How to connect Monitor 17
Specification
- Color Camera 18
- B/W Camera 19
Trouble shooting guide 20-21
Note 22
Please study the manual thoroughly in order to get the best
performance from the camera.
Model configuration
■ KCC-34 Series (380 TV Lines, 0.1 Lux/F1.4)
KCC-34(12)
DC12V Only
KCC-34(24) DC12V~AC24V, Non polarity Dynamic power input
KCC-34(230L) AC230V (AC200~AC240V)
■
KCC-34X Series (380 TV Lines, 0.01 Lux/F1.4 with EX-view HAD CCD)
KCC-34X(12)
DC12V Only
KCC-34X(24) DC12V~AC24V, Non polarity Dynamic power input
KCC-34X(230L) AC230V (AC200~AC240V)
■
KCC-340 Series (480 TV Lines, 0.1 Lux/F1.4)
KCC-340(12)
DC12V Only
KCC-340(24) DC12V~AC24V, Non polarity Dynamic power input
KCC-340(230L) AC230V (AC200~AC240V)
■
KCC-340X Series (480 TV Lines, 0.01 Lux/F1.4 with EX-view HAD CCD)
KCC-340X(12)
DC12V Only
KCC-340X(24) DC12V~AC24V, Non polarity Dynamic power input
KCC-340X(230L) AC230V (AC200~AC240V)
■ IR Sensitive for Day & Night application
Model nr+IR (ex:KCC340(24)IR)
■
KCB-34 Series (420 TV Lines, 0.05 Lux/F1.4)
KCB-34(12)
DC12V Only
KCB-34(24) DC12V~AC24V, Non polarity Dynamic power input
KCB-34(230) AC230V (AC200~AC240V)
■
KCB-34X Series (420 TV Lines, 0.01 Lux/F1.4 with EX-view HAD CCD)
KCB-34X(12)
DC12V Only
KCB-34X(24) DC12V~AC24V, Non polarity Dynamic power input
KCB-34X(230) AC230V (AC200~AC240V)
■
KCB-340 Series (600 TV Lines, 0.05 Lux/F1.4)
KCB-340(12)
DC12V Only
KCB-340(24) DC12V~AC24V, Non polarity Dynamic power input
KCB-340(230) AC230V (AC200~AC240V)
■
KCB-340X Series (600 TV Lines, 0.01 Lux/F1.4 with EX-view HAD CCD)
KCB-340X(12)
DC12V Only
KCB-340X(24) DC12V~AC24V, Non polarity Dynamic power input
KCB-340X(230) AC230V (AC200~AC240V)
This unit has been tested and proved to comply with the limits of FCC rules
and CE regulation.
Color Camera
B/W Camera
