Kodak KB28

3
10 VIEWFINDER EYEPIECE
11 FILM-SPROCKET TEETH
12 FILM CHAMBER
13 FILM-DOOR LATCH
14 CAMERA STRAP
15 FILM SPINDLE
16 FILM TAKE-UP SPOOL
17 FILM-LOAD MARK
18 FILM DOOR
19 FILM WINDOW
LOADING THE BATTERIES
This camera uses 2 AAA-size
alkaline 1.5 V batteries.
1. Load the batteries
as shown.
• Make sure you tuck
the battery pull
strap into the
battery chamber
before inserting
the batteries.
2. Replace the batteries
with fresh alkaline
batteries when the
FLASH - READY LIGHT (9)
takes more than 30
seconds to come on.
