Figure 39 Carburetor Heater Location on 20 and 26 kW Models
Figure 40 Power Connections for Carburetor Heaters
Carburetor heater location under air cleaner. Insert
from the back of the generator set.
Carburetor heater
adv-8954
tt1482b
20 kW Model
26 kW Model
Carburetor heater
120 VAC receptacle location
Knockouts for 240 VAC plugs
