TP-5592 7/96 Specifications 1-1
Section 1. Specifications
General Specifications—1-Phase Models
13.5CCOZ
11CCFOZ
18.5CCOZ
15CCFOZ
21CCOZ
16.5CCFOZ
18CCFOZ *
Dimensions—in. (mm)
Length 36.62 (930) 41.35 (1050)
Width 22.31 (567) 22.31 (567)
Height 26.01 (661) 26.42 (671)
Length w/sound shield 41.24 (1047) 44.75 (1137)
Wisth w/sound shield 25.75 (654) 25.75 (654)
Height w/sound shield 28.25 (718) 28.75 (730)
Weight (wet)—lbs. (kg) 680 (308) 765 (347) 790 (358)
w/sound shield (wet)—lbs. (kg) 775 (352) 870 (395) 895 (405)
Air Requirements—CFM (L/min.)
Combustion 60 Hz/50 Hz
86.78/72.32
(1422/1185)
115.91/96.59
(1899/1582)
Cooling 60 Hz/50 Hz
210/175
(5946/4955)
Angular Operation (max.)
(in all directions)
25_ continuous, 30_ intermittent
(three minutes or less)
Minimum clearances for vibration and
cooling (top, front, rear, and sides)
(without sound shield)—in. (mm)
1.5 (38)
Fuel Consumption 60 Hz—U.S. Gal./Hr. (L/Hr.)
(Fuel consumption based on CCOZ120/240 voltage configuration)
LOAD
25% 0.48 (1.8) 0.63 (2.4) 0.67 (2.5)
50% 0.71 (2.7) 0.90 (3.4) 0.98 (3.7)
75% 0.93 (3.5) 1.24 (4.7) 1.37 (5.2)
100% 1.19 (4.5) 1.63 (6.2) 1.77 (6.7)
Fuel Consumption 50 Hz—U.S. Gal./Hr. (L/Hr.)
(Fuel consumption based on CCFOZ110/220 voltage configuration)
LOAD
25% 0.38 (1.4) 0.50 (1.9) 0.53 (2.0)
50% 0.54 (1.9) 0.72 (2.7) 0.77 (2.9)
75% 0.72 (2.7) 1.00 (3.8) 1.05 (4.0)
100% 0.93 (3.5) 1.38 (5.2) 1.40 (5.3)
* 18CCFOZ -- 50 Hz only
