TP-6329 8/0736 Section 5 Controller
Battery voltage (Bt). This setting toggles between 12
and 24 VDC for the engine starting battery voltage. The
15/30RYG uses a 12-volt battery, Bt12.
Communications setting (Cn). This setting allows the
user to set the controller for communication with
optional meters. The 15/30RYG is factory-set for no
CAN communications, Cn00. Change this setting if the
optional Remote Digital Gauge is used.
Parameter Setting
Description
Voltage, VAC Frequency, Hz Phases, Wires Connection
Unit’s system voltage and
frequency, 15RYG
Uu01 120/240 60
Single phase, 3 Wire
1PH
Uu04 277/480 60
Three phase, 4 Wire
Wye
Uu10 * 120/240 60
Three phase, 4 Wire
Delta
Uu10 * 139/240 60
Three phase, 4 Wire
Wye
Uu11 * 120/208 60
Three phase, 4 Wire
Wye
Uu16 * 127/220 60
Three phase, 4 Wire
Wye
Unit’s system voltage and
frequency, 30RYG
Uu01 120/240 60
Single phase, 3 Wire,
1PH
Uu03 230/400 50
Three phase, 4 Wire
Wye
Uu04 277/480 60
Three phase, 4 Wire
Wye
Uu07 * 110/220 50
Single phase, 3 Wire
1PH
Uu10 * 120/240 60
Three phase, 4 Wire
Delta
Uu10 * 139/240 60
Three phase, 4 Wire
Wye
Uu11 * 120/208 60
Three phase, 4 Wire
Wye
Uu16 * 127/220 60
Three phase, 4 Wire
Wye
Uu17 * 110/190 50
Three phase, 4 Wire
Wye
Uu17 * 110/220 50
Three phase, 4 Wire
Delta
Uu18 * 120/208 50
Three phase, 4 Wire
Wye
Uu21 * 220/380 50
Three phase, 4 Wire
Wye
Uu22 * 240/416 50
Three phase, 4 Wire
Wye
Uu23 * 115/200 50
Three phase, 4 Wire
Wye
Unit configuration Uc01 Standby
Engine type Ec03 15RYG
Ec06 30RYG
Engine data input types Ed01 15/30RYG factory setup
Battery voltage Bt12 12 VDC
Communications Cn00 No CAN communications
Cn01 J1939 (use for Remote Digital Gauge)
Cn06 [ Enables J1939 communications and 1-hour ADC power down after engine stop
for either:
a. Remote start/stop switch
b. Automatic transfer switch
c. Remote Digital Gauge with remote start/stop switch and replacement harness
* ADC application program version 1.20 or higher
[ ADC application program version 1.21 or higher
Figure 5-1 Configuration Parameters
