Kohler 6600 Series

8
Specifi cations
KohlerEngines.com 32 690 03 Rev. I
Engine Dimensions with Low Profi le or High Performance Air Cleaner-Starter Side
A
B
C
D
E
F
G
H
A
55.8 mm (2.20 in.)
Starter Stud
B 13.0 mm (0.51 in.) C Mounting Hole "A" D 40.8 mm (1.61 in.)
E
Engine Mounting
Surface
F
72.0 mm (2.83 in.)
Exhaust Port #2
G
92.0 mm (3.62 in.)
Exhaust Port #1
H
154.0 mm (6.06 in.)
Spark Plug Center
Line
