Kohler BARDON - Installation; Installation Steps

-4-
3. Insert screws into dowels and tighten them. (Fig.2)
3. ( 2)
4. Connect AC power cable (Fig.3). The cable can be hidden.
4. ( 3)
Fig.2
2
Fig.3
3
INSTALLATION
A. Installation Steps
1. Paste the installation template at appropriate location on
the wall.
2. Drill four holes, dia 8mm insert plastic dowels. (Fig.1)
2. 8mm
(1)
A.
1.
8mm
Fig.1
1
Cap
Null Line
Grounding Line
Power Line
