11.12

Section 11

Reassembly

Figure 11-45. Installing Valve Retainers.

Install Cylinder Head

1. Check to make sure there are no nicks or burrs

on the sealing surfaces of the cylinder head or

crankcase.

2. Rotate the cranksha to position the piston at

TDC on the compression stroke.

3. Install the dowel pins into the recesses around the

lower cylinder head bolt holes. See Figure 11-46.

Head

Gasket

Dowel Pins

Figure 11-46. Installing Dowel Pins and New Head

Gasket.

4. Install a new cylinder head gasket.

5. Install the cylinder head and start the four hex

ﬂ ange screws. Torque the screws in increments

using the sequence shown. See Figure 11-47.

Torque the hex ﬂ ange screws following the table.

Model Initial Torque Final Torque

CH270 12 N·m (106 in. lb.) 24 N·m (212 in. lb.)

CH395,CH440 18 N·m (159 in. lb.) 36 N·m (319 in. lb.)

Figure 11-43. Connect Kill Wire To Module.

Assemble Cylinder Head

1. Install the valves into their respective positions.

2. Install new valve seals on the stem of the valves.

See Figure 11-44.

Module Terminal

Route Wire Here

Figure 11-44. Valve Stem Seals.

NOTE: The engine utilizes valve stem seals on the

valves. Always use a new seal when valves

are installed in the cylinder head. Never

reuse old seals.

3. Install the valve springs and retainers into their

respective locations in the cylinder head. Support

the valve heads from underneath. Using hand

pressure, compress each valve spring and slide

each retainer onto the valve stem to lock in place.

See Figure 11-45.

Valve Seals
