Fixed Ignition System
This system uses a capacitive discharge (CD) coil. Ignition timing and spark remains constant regardless of engine
speed. Timing of spark is controlled by location of fl ywheel magnet group as referenced to engine TDC. A typical fi xed
ignition system consists of:
● 1 magnet assembly which is permanently affi xed to fl ywheel.
● 2 electronic capacitive-discharge ignition modules which mount on engine crankcase.
● 1 kill switch (or key switch) which grounds modules to stop engine.
● 2 spark plugs.
A Spark Plug(s) B Oil Pressure Switch C Oil Sentry
™
(Green) D White Kill
E
Flywheel Stator
Assembly
F Ignition Module G
Non-Smart Spark
™
Ignition
H
Rectifi er-Regulator
Connector
I Rectifi er-Regulator J Oil Sentry
™
Kill (Green) K Violet B+ L
Solenoid Shift Starter
Assembly
M Starter Solenoid Tang N Starter Solenoid Stud O Fuse P Blue
Q
Alternate Ignition Kill
(–)
R White S Accessory Terminal (+) T Yellow
U Ignition Kill V Red W Carburetor X Carburetor Solenoid
Y Black (Ground) Z Intake Manifold Screw AA Black AB
Oil Sentry
™
Panel
Light/Remote Light
AC Oil Sentry
™
Light AD Connector AE Magneto AF Key Switch
AG Accessory AH Battery AI Starter AJ Ground
AK Key Switch Ground AL Rectifi er AM Blue/Red AN Battery Positive
AO Battery Negative
To Next Page
