WET DISC TYPE CLUTCH (if equipped)
Wet Disc Type Clutch Components
I
J
M
W
P
N
L
H
G
A
E
F
O
S
R
T
U
V
K
D
C
B
Q
A Shifting Lever B Gasket C Seal D Shaft (Yoke)
E Nameplate F Clutch Housing G Adjusting Ring H Driven Member
I Release Sleeve J
Bearing Release
Assembly
K Pressure Plate L Pilot Bearing
M Adjusting Lock N Clutch Assembly O Key P Power Shaft
Q Retaining Rings R Yoke S Roll Pin T Oil Seal
U Ball Bearing V Snap Ring W Clutch Assembly
