Kohler Command PRO ECH749 Service Manual

BLACK GREY
A B A B A B C DA B C 1 2 31 2A B C A B1 2
1 2
Fuel
Injector
#1
Fuel
Injector
#2
Ignition
Coil
#1
Ignition
Coil
#2
Crankshaft
Position
Sensor
Oxygen
Sensor
Throttle
Position
Sensor
Manifold
Absolute
Pressure
Sensor
Intake
Air
Temperature
Sensor
Oil
Temperature
Sensor
Battery
Fuel Pump
MIL
19
1018
19
1018
RED
WHITE
WHITE
BLACK
BLACK
BLACK
BLACK
YELLOW
BLACK BLACK BLACK
BLACK
BLACK
RED/BLACK
GREY GREY
PURPLE
PURPLE
PURPLE PURPLE
TAN
TAN DARK BLUE
DARK BLUE
DARK BLUE
DARK BLUE
Key Switch
DARK
GREEN
DARK GREEN DARK GREEN DARK GREEN YELLOW
YELLOW
PINK
LIGHT GREEN RED/BLACK
RED/BLACK
RED/BLACK RED/BLACK RED/BLACK RED/BLACK
E D
A
C
B
Stator
Rectifier-
Regulator
Starter
Motor
RED
Accessory
10A Fuse
5-Terminal
Connector
30A Fuse
1 2
3
4
Diagnostic
Connector
10A Fuse
Oil
Pressure
Switch
YELLOW
RED/BLACK
31 2
WHITE
5-Terminal Engine Mounted Key Switch

Kohler Command PRO ECH749 Specifications

General

Fuel System	Carburetor
Starter	Electric
Governor Type	Mechanical
Lubrication System	Full Pressure
Fuel Type	Gasoline
Crankshaft Orientation	Horizontal
Bore	3.27 in (83 mm)
Cooling System	Air
Oil Type	SAE 10W-30
Spark Plug Gap	0.030 in (0.76 mm)
Valve Clearance - Intake	0.004 - 0.006 in (0.10 - 0.15 mm)
Crankshaft Type	Varies by model
Crankshaft Thread Size	Varies by model
Crankshaft Length	Varies by model
Crankshaft Diameter	Varies by model
Type	Overhead Valve (OHV)
