Air Cleaner
Cover
B Debris Screen C Fuel Filter D Oil Filter
E Oil Fill/Dipstick F Oil Drain Plug G Spark Plug H Bail
I Paper Element J Precleaner K
Air Cleaner
Base
L
Low-Profi le Air
Cleaner
M
Heavy-Duty Air
Cleaner
N Starter Handle O
Retractable
Starter
Visit KohlerEngines.com for service parts information and purchasing options.
Pre-Start Checklist
1. Check oil level. Add oil if low. Do not overfi ll.
2. Check fuel level. Add fuel if low. Check fuel system components and lines for leaks.
3. Check and clean cooling areas, air intake areas and external surfaces of engine (particularly
after storage).
4. Check that air cleaner components and all shrouds, equipment covers, and guards are in place
and securely fastened.
5. Check spark arrestor (if equipped).
