5. Install the Soap Dispenser - Style B
Slide the gasket onto the pump assembly.
Insert the blunt end of the tube into the bottom of the pump
assembly.
Position the assembly in the desired mounting hole.
From underneath the sink, thread the nut onto the pump
assembly. Securely hand tighten the nut.
Fill the bottle with soap/lotion.
Slide the bottle opening over the tube and thread the bottle into
the pump assembly until secure.
Pump Assembly
Gasket
Nut
Tube
Bottle
Kohler Co. 7 1036178-2-F
