Kohler K-12177 - Install the Escutcheon; 1-Hole Installation; 3-Hole Installation

1. Install the Escutcheon (Optional)
For 1-hole Installations:
Apply a bead of plumbers putty to the underside of the
escutcheon according to the manufacturer’s instructions.
Position the escutcheon over the sink hole, align, then press into
place.
Remove any excess putty.
For 3-hole Installations:
Apply a bead of plumbers putty or other sealant to the bottom
edges of the undercover according to the manufacturer’s
instructions.
Position the undercover over the sink hole, align, then press into
place.
Remove any excess putty.
Place the escutcheon over the undercover.
Escutcheon For
Three-Hole Sinks
Escutcheon For
One-Hole Sinks
Faucet
Undercover
1004614-2-E 4 Kohler Co.
