3. Install the Drain Clamp
NOTE: If using 2x6 studs, install the drain mounting frame in the
back notches as shown.
Install the drain mounting frame into the front notches on the
bottom of the carrier.
Insert the PVC elbow into the mounting frame.
Secure the elbow in place with the drain clamp. Push the clamp
into the frame until it locks into place.
Back View
2x62x4
Kohler Co. 7 1247365-2-B
